NYTEMP®

NYTEMP® is the most advanced high temperature self-locking patch material available in the fastener industry. NYTEMP® product can create positive resistance to vibration and loosening in high temperature environment after the fastener is installed.

Product Advantages

  • Meets NASA’s low outgassing requirements
  • Patch-type non-metallic locking element – eliminates the need for metal removal that can reduce fastener strength and performance
  • Vibration resistant: MIL-STD-1312 #7
  • Temperature range: -70˚ F (-50˚ C) to 450˚ F (232˚ C)
  • Variable patch length and location
  • Patch can be applied to both internal and external thread fasteners of all types: nuts, screws, bolts, studs and specials

TDS : Download   Enquire Now

Description

Product Advantages

Torque and clamp load stability up to 232℃ (450℉), more than any other patch materials available today
 No additional locking device needed
 Complies with and exceeds IFI-125 and IFI-525 and most automobile specifications
 Can be applied on internal or external threaded fasteners
 Ready for assembly
 Long product shelf life (unaffected by atmospheric condition)
 Non-tacky finish, dry-to-the-touch
 Non-toxic, assembler friendly
 Environment-friendly

Industrial Specifications and Standards

Company Specification Company Specification
Industrial Fasteners Institute(IFI)  IFI-100/107
IFI-124
IFI-524
IFI-155
IFI-555		 American Military/ Aviation MIL-DTL-18240
MILF-18240
NAS1283
QPL-18240-33
NASM25027
NASM15981
General Motors GM6189P+High Temp ANSI ANSI B.18.16.1M
Detroit Diesel TES-113 NASA SP-R-0022A

Specification

Properties Description Properties Description
Color  Orange (Other color available upon request) Coating range 90°~180° or 360°
Operation temperature -56℃~232℃ Hardness ROCKWELL R106-109
Acid/alkaline resistance Good Resistance to Weak acid/Alkaline
